Common Mode Choke (E-Core)
- Wide Range of currents and inductances available.
- 0.50 Amps to 4 Amps.
- 0.35 mH to 14.3 mH.
- Cost effective design.
- Low interwinding capacitance.
- Class B (130°C) insulation.
- 3750 Vrms isolation between windings.
| Product | Max RMS Current (A) | Lp (mH) | Max DCR per Winding (Ω) |
|---|---|---|---|
| 320-0561 | 1 | 32 | 0.712 |
| 320-0562 | 1 | 56 | 0.98 |
| 320-0547 | 1 | 72 | 1.28 |
| 320-0548 | 1 | 125 | 1.145 |
| 320-0556 | 2 | 1.13 | 0.075 |
| 320-0563 | 2 | 16 | 0.27 |
| 320-0564 | 2 | 28 | 0.37 |
| 320-0549 | 2 | 36 | 0.447 |
| 320-0550 | 2 | 62 | 0.412 |
| 320-0557 | 2.5 | 0.89 | 0.055 |
| 320-0558 | 3 | 0.68 | 0.04 |
| 320-0559 | 3.5 | 0.5 | 0.027 |
| 320-0560 | 4 | 0.35 | 0.023 |
| 320-0565 | 4 | 8 | 0.085 |
| 320-0545 | 4 | 14 | 0.13 |
| 320-0551 | 4 | 19 | 0.265 |
| 320-0552 | 4 | 32 | 0.122 |
| 320-0546 | 6 | 6.6 | 0.06 |
| 320-0553 | 6 | 15 | 0.118 |
| 320-0554 | 6 | 11.5 | 0.1 |
